Victor Type 55 Multi-Flame Heating Nozzles

For use with alternate fuels - Not for use with Acetylene

Victor Heavy Industry The Type 55 Series multi-flame heating nozzles feature a raised center point on the head to prevent bumping the plate and compressing the flame. The center point and improved mixer design combine to provide greater resistance to sustained backfire and improved flow performance.

High capacity heating head for heat treating, straightening, & priming

  • Type 55 Series multi-flames are available as components
  • Threaded elbows give you the flexibility to easily service or extend the length of the nozzles
  • Use the special extensions adapter to extend the tip tube to the required length

    Specifications

    Part Number
    		 Tip Size Overall Length Torch Handle Series*
    0323-0326 20
    		 711.2 mm ( 28 in. ) HD 310C
    0323-0325
    		 15 711.2 mm ( 28 in. ) HD 310C
    0323-0324
    		 10
    		 711.2 mm ( 28 in. ) HD 310C
    0323-0328
    		 8 279.4 mm ( 11 in. ) HD 310C / 300
    0323-0327
    		 6 279.4 mm ( 11 in. ) 300

    *Size 10, 15 and 20 Type 55 heating nozzles must be used with HD 310C torch
    handle and 3/8" (9 5 mm) hose.

    Heat Output:
