Miller® ArcReach® SuitCase® 12 Wire Feeder Package

ArcReach® SuitCase® 12, Bernard™ BTB 300 A Gun Pkg

Setting the standard for performance

Heavy-duty drive motor with tachometer control provides wire feed speed that is accurate and consistent from the start of the weld to the finish and from one weld to the next, which provides consistent arc quality. Wide voltage range for small and large wires with no contactor chatter or arc outages

Durable design reduces downtime

Impactresistant case and the elimination of feeder control cords provides a solid solution to last in harsh environments.

Specifications

• Number of rollers: 2
• Arc Voltage range: 14 - 48 VDC / 110V Max OCV
• Input Circuit Capacity: 330A @ 60% duty cycle
• Wire Speed: 50 - 780 IPM
• Wire Diameter: .023" - 5/64" (0.6mm - 2.0mm) Solid Wire, .030– 5/64 in. (0.8–2.0 mm) Flux Core
• Package Part Number: 951729001

Full Product Spec Sheet

Features

• More Jobsite Productivity and Efficiency
• Cable Length Compensation

• Heavy-duty drive motor with tachometer control
• Unique and Durable Case

• Extreme reliability potted and trayed main printed circuit board
• Ultra-low Drag Inlet Guide Pins

• Scaled Wire Pressure Knob
• Digital Meters with SunVision™ Technology


What's Included

• ArcReach® SuitCase® 12

• .045 - 1/16 reversible dual VK (flux core) drive rolls

• Bernard™ BTB Gun 300 AMP, 15FT

• Centerfire contact tips, .045 (QTY 3), .052 (QTY 2)
