Upgrade your welding helmet with the Lincoln Electric VIKING™ 2x4C® GOLD Series Auto-Darkening Lens with Digital Controls. Engineered with 4C® Lens Technology, this premium auto-darkening cartridge delivers exceptional 1/1/1/2 optical clarity and broadens the viewable color spectrum for a true-color view of the arc, puddle, and base material.
Featuring digital controls, a bright 2.5 light state, variable shades 8–13 and shade 5 cutting/grinding option, adjustable sensitivity, and delay controls, the KP5561-2 provides complete control and reduced eye strain for all-day comfort. Designed with a gold lens view, high-temperature housing, solar rechargeability, and replaceable batteries, it fits seamlessly into most 2" x 4.25" cartridge helmets.
Allows magnifying cheater lenses or inside cover lenses to clip directly to the lens cartridge for maximum flexibility.
Variable Shade 2x4C Lenses are slightly thicker than fixed shade lenses. When using a variable shade lens in a flip-up attachment, confirm that your lens slot will accommodate the 0.31" cartridge thickness. If the lens slot is too narrow, some can be manually filed down to fit the variable shade cartridge.
Technical Specifications |
|
| Part Number | KP5561-2 |
|
Description
|
VIKING™ 2x4C® Auto Darkening Lens w/ Digital Controls - Variable Shades 5, 8-13 - Gold Lens
|
| Lens Color | Gold |
| Optical Clarity | 1/1/1/2 |
| Inactive Shade (Light State) | Shade 3 |
| Active Shades | 5, 8–13 |
| Power Supply | Battery w/ Solar Cell |
| Switching Speed | 1/25,000 sec |
| Arc Sensors | 2 |
| Sensitivity Control | Adjustable |
| TIG Amp Rating | 5 Amps |
| Cartridge Size | 4.25 in x 2.00 in x 0.31 in (108 mm x 55 mm x 8 mm) |
| Viewing Area | 3.63 in x 1.38 in (92 mm x 35 mm) |
| Warranty | 2-Year Hassle Free |
Click Here for full Viking 2x4C Information
