Harris 25GX-145-540 Oxygen Regulator
Model 25GX single-stage regulator is designed to be the next generation workhorse of the Harris industrial line. It features larger, easy-to-read gauges and an ergonomic adjusting knob that also shields the adjusting mechanism from contaminants.
Features
- High end features for economical price
- Workhorse of Harris industrial regulator line
- Ergonomic ABS plastic knob for easy grip and precise adjustment
- Brass body and chrome-plated zinc bonnet for longer service life
- Neoprene diaphragm for better pressure control
- 2.5" Steel dual scale easy-to-read gauges
- One-piece encapsulated seat design with internal filter to protect the PTFE Teflon® seat from particulate contamination
- UL® listed /CGA E-4
-
Featured In: Steelworker® Classic & V-Series® kits
-
Weight: 2.9 lbs./1.32 kg
25GX-145-540 Specifications
- Max Inlet Pressure: 3000 psi.
- Outlet Pressure: 0-145 psi
- Inlet Connection: CGA 540
- Outlet Connection: 9⁄16" - 18 LH
