Fireball Pro Welding Fixture Table Kit 6' x 3' (72" x 36" x ½")


The Pro table is Fireball’s most accessible and affordable option, designed for light-duty fabrication where flexibility and mobility matter most. Its steel frame is highly customizable — you can weld to it, add brackets, and adapt it to unique setups. It also works as a retrofit on top of an existing plate steel workbench, instantly upgrading it with a precision-hole surface. Two people can easily lift it into the back of a pickup truck, making it the most mobile table in the lineup.

Fireball plate is made from hot rolled A572 Steel equivalent which is ground and machined for flatness. A572 is a higher strength version of A36, a common structural grade steel.

Features

  • Coating- Corrosion, spatter, and scratch resistant Dragon Scale
  • Ribbing- Full height 4" ribbing engineered to torsional rigidity
  • Holes- All counterbore and chamfered on back sides
  • Side face on the tables are 4" tall with 1 row of holes.
  • The modular leg accessory system provides an extensive range of customization options.
  • 1/2" thick table that shares all the same fixtures as the 1" thick table.
  • Flatness (+/- .005) full length, corner to corner
  • Legs: Height Adjustable Level Pads

Best Suited For

  • Students and educational facilities — high schools, colleges, and training programs
  • Home hobbyists — side projects and personal builds
  • Small robotic welding stations — a compact and cost-effective fit-up surface
  • Light fabrication and general repair work
  • Farm maintenance — repairing buckets, implements, and equipment

Assembly Required

This table requires assembly by the customer. When you purchase the table kit, the plate, mounting hardware, tubular frame, and legs are all included.

Full assembly will require welding and/or drilling:

  • The table top does not need to be welded to the frame. For best flatness we suggest just bolting to the frame using the included steel straps
  • Tube frame does not need to be welded together, welding is optional
  • The legs require welding to attach the foot plate and nuts for the leveling feet
  • Attaching the legs to the frame requires welding or drilling/bolting
  • Attaching leg braces to the legs requires welding or drilling/bolting
