Canaweld Multi-Process 221 SLM MIG-TIG-Stick Welder
- Regular
- $1,664.00
- Sale
- $1,664.00
- Regular
- $1,736.00
Sold Out
- Unit Price
- per
Canaweld Multi-Process 221 SLM
The Multiprocess 221 SLM is a powerful, portable, and intelligent welding machine. This unit is capable of MIG welding, stick welding and TIG welding with a lift start in manual or synergic mode.
The combination of synergic control and job programming ability makes this unit user-friendly for less experienced welders looking to perform high quality welds. It features a user-friendly panel which walks the user through setup one step at a time and then automatically adjusts its parameters to meet the required use.
The voltage of this unit is selectable between 230 V (±15%) or 115 V (±15%) which makes it suitable for any single voltage electrical network. It is the perfect choice for anyone; from a novice to the professional welder who has speed and quality in mind.
The Multiprocess 221 SLM is capable of welding with Canaweld’s spool gun which ensures trouble-free Aluminum MIG welding.
Options:
- MIG Package - PLC7580158 MULTI-PROCESS 221 SM, Silver
- MIG/TIG Package - PLC7580159 MULTI-PROCESS 221 SM, Gold
- MIG/TIG Package with wheel kit - PLC7580160 MULTI-PROCESS 221 SM, Gold PLUS
Features:
- LCD display for quick intuitive setup whether you are an expert or beginner.
- Digital control of the welding parameters based on the type of material, gas and wire diameter to be used.
- Built-in polarity changeover feature for most common gas and gasless wires Lift TIG Arc start.
- Professional wire feeding mechanism with 30mm rolls and sealed dust-proof motor
- Double groove rolls replaceable without any tools.
- ‘Energy Saving’ function to operate the power source cooling fan when necessary.
- Spool Gun Compatible
- Adjustable inductance, Burn Back and ARC Force control.
- TIG Hot Start and Post-flow Gas Control.
- Both 8 and 12-inch (203 and 305 mm) Wire Spool Size.
- Metal face panel.
- Comprehensive 3 Year Warranty
| Product Name | Canaweld Multi-Process 221SLM |
| Welding Processes | MIG (GMAW), Flux Core (FCAW), TIG (GTAW), Stick (SMAW) |
| Input Voltage | 120V or 230V Dual Input |
| Input Current | 120V: 17.5 - 31.5A 230V: 9.8 - 29.8A |
| Welding Output Amps (120V) | MIG: 10 - 140A TIG: 10 - 140A Stick: 10 - 110A |
| Welding Output Amps (230V) | MIG: 10 - 210A TIG: 10 - 200A Stick: 10 - 200A |
| Output Current | DC - CC/CV |
| Aluminum TIG | ❌ |
| TIG Arc Starts | Lift Tig (No High Frequency) |
| Spool Gun Ready | ✔️ - Canaweld 150A Spool Gun |
| Dimensions | 24.4" x 13.3 " x 16.1" |
| Weight | 49 lb without spool |
| Warranty | 3 Year Comprehensive, serviced by Canaweld |
What's in the box?
- Canaweld 221 SLM Multiprocess welding power source
- Ground Clamp and Stick Electrode Holder (10 ft. Length)
- MIG Torch and Consumable Set (10 ft. Length, Tweco Consumables)
- Argon/Co2 MIG & TIG Regulator with 10 ft. Gas Hose
- Drive Rolls: .030"-.040" Solid Wire (V Groove), .030-.035" Flux Cored Wire (Knurled)
- 120/230V Adapter Plug
MIG/TIG Gold package also includes:
- 200A Tig Torch with Momentary PushButton Control (26 Style, 12 ft. Length)
- TIG Starter Kit and Tungsten Electrode Sample
MIG/TIG Gold PLUS package also includes:
- Swivel Caster Package
