Standard Duty Welding Fixture Table 8.5' x 4.5' (102" x54" x 6") (TCF)

Standard Duty 8.5' x 4.5' (102" x54" x 6")

If the Pro table is a light-duty option, the Standard Duty is the table for everyone else. Think of it as the Honda Civic of fixture tables — reliable, capable, and built to handle virtually any job a professional fabricator will throw at it on a daily basis. It is the most popular choice across the Fireball lineup.

The Standard Duty features one-piece cast iron construction with heavy ribbing underneath, delivering exceptional stiffness and rigidity. Cast iron is naturally spatter-resistant, meaning weld spatter is far less likely to stick compared to regular plate steel. You can fully weld out directly on the Standard Duty fireballtool.com | Fireball Tool — Engineered for the Serious Fabricator — it’s built for it — and torch heat can be applied directly to the cast iron without causing damage.

Best Suited For:

Professional fabricators and small shop owners
Everyday production welding and fabrication
Users who want a serious, no-compromise table at an accessible price point
Second-floor shops where floor load capacity is a concern — the Standard Duty is significantly lighter than the Heavy Duty

Features

Coating- Corrosion, spatter, and scratch resistant Dragon Scale
Ribbing- Full height 6" ribbing engineered to torsional rigidity
Holes- All counterbore and chamfered on back sides
Side face on the tables are 6" tall with 1 row of holes.
The modular leg accessory system provides an extensive range of customization options.
1/2" thick table that shares all the same fixtures as the 1" thick table.
Flatness (+/- .005) full length, corner to corner

Leg Option	Leg Height	Table Surface Height	Leveling Pad	Static Load Capacity	Weight
Fixed Height	26"	34"	+/- 1"	2,000 lbs	30.8 lbs
Adjustable Height	24" - 38"	32" - 46"	+/- 1"	2,000 lbs	40.7 lbs
Adjustable Height + Caster	22" - 30"	30" - 35"	+/- 1"	1,700 lbs	36.3 lbs
