Mosa Magic Weld 200A



The Mosa Magic Weld 200A DC arc welding machine is a lightweight and compact welding generator.  Designed for professionals, with the capability of delivering up to 200 A with a duty cycle of 60%! - Yes that is not a typo 60% duty cycle and weighing in at only 135 lbs!

  • DC arc welding machine
  • Honda GX 270 8.5 HP Engine for reliable power and simple maintenance
  • Fuel type (gasoline)
  • Fuel consumption 1.5 L/hr at 60% Capacity (120A)
  • Welding with any type of electrode including cellulostic electrodes
  • High-frequency voltage control and welding current
  • High performance permanent magneto alternator
  • Single-phase auxiliary current 50Hz generated inverter
  • Auxiliary current AC With micro-breaks for tool protection
  • Engine stop for low oil level
  • Economizer function
  • Mosa Patented "Power Optimizer" allows for peak welder performance without overloading or damaging drive engine
  • Full steel frame for machine protection
  • CE Certified
  • Permanent magnet alternator, self-excited, brushless
  • Dinse 35 (50mm) connections (connectors not included)
  • Made in Italy
  • Two year Mosa Warranty

Options

  • Basic Package
  • Add Wheel & Handle Kit

Please note, extra freight charges apply due to heavy weight.

Mosa Magic Weld 200 User Manual    Honda GX 270 Manual

Adjustment Range  20 – 200A
 Duty Cycle  200A – 60%
 Fuel Tank Size  5.3L (3.5 hours welding time)
Open Circuit Voltage 70V
 Single Phase Power Max  3.25KW / 230V cc / 14.1A – 50Hz
 Continuous Single Phase Power  2.8KW / 230V cc / 12.2A – 50Hz
Auxiliary Power: 1x 120V AC 60Hz, 2.1kW, 18.3A
 Dimension 630 x 490 x 540 MM / 24.75 x 19.30 x 21.25 IN
 Weight 61 Kg / 135 Lbs
