Optrel Panoramaxx Hybrid CLT Laser / Arc Welding Helmet
- Regular
- $1,001.00
- Sale
- $1,001.00
- Regular
Sold Out
- Unit Price
- per
Optrel Panoramaxx Hybrid CLT Laser-Welding Helmet
Hybrid laser & traditional welding helmet - Change seamlessly between processes!
The ideal companion for hand-held laser welding and conventional arc welding
During laser welding, the infrared radiation can cause immediate and irreparable damage to eyesight due to its deep penetration depth. Damage is even possible from reflections. Suitable eye as well as face protection is therefore essential.
- Panoramic XXL field of view
- EN379 classification 1/1/1/2
- Shade levels 4-12
- ShadeTronic®
- Fadetronic
- Rechargeable battery unit with charging via the welding arc
- 5-point multi-detection sensors
NEW Position Locker
The new two-position locking function for a safely open or closed helmet. Now standard with all Optrel Panoramaxx series welding helmets and with the IsoFit® headgear.
Features and Technical Specs
- Detection of the arc brightness and fully automated shade level adjustment from 4 to 12
- Sensitivity Control prevents ADF from responding too soon or not at all to their arc flash
- Opening Delay: Adjust the time it takes to switch from dark to light
- Curved helmet optimized for overhead welding
- Meets CSA standard Z94.3
- Part No. 1010.302
| Shade levels | Light state: shade level 2.5/4.0 Manual: Shade levels 3-8 ShadeTronic : Automatic Shades 4-12 |
| Energy supply | 280mAh Li-Polymer battery rechargeable via micro USB connector and solar cell |
| Battery life range | 300 to 500 charging cycles |
| Sensors | Five sensors |
| Sensitivity | continuously, new with “Super High” sensitivity |
| Switching time | 0.090 ms at 20°C 0.070 ms at 55°C dark to light: 0.1 s to 2.0 s (with FadeTronic) |
| Field of vision | 2.3 to 6.3 times bigger than a 100 x 50 mm standard ADF |
| Classification EN379 | 1/1/1/2 |
| Shape stability | Mask: up to 220°C Front cover lens: up to 137°C |
| Eye protection | Ultraviolet/infrared protection: Maximum in the entire protection level range Visible range activated: Protection level 4 – 12 (ShadeTronic®), 3-8 (manual) Visible range not activated: Protection level 2.5 |
| Operating temperature | -10°C to + 55°C / 14°F to 131°F |
| Storage temperature | -20°C to + 70°C / -4°F to 158°F |
| Weight | 685 grams |
| Warranty | 2 Years, 3 Years with registration |
Components and Markings:
| Component | Protection Group | Marking |
| Laser filter panoramaxx hybrid clt | Eye- protection | 16321 OS W2.5/3-8/4<12 V2 +TIG 1000-1100 D LB7 IR LB8 OS 1000-1100 OD7 C5 PS3 ISO 19818-1 OS CE |
| Laser protection frame | Eye- protection | 1000-1100 D LB7 IR LB8 OS 1000-1100 OD7 C5 PS3 ISO 19818-1 OS CE |
| Welding shell (Polyamide) | Face- and head- protection | 16321 OS W15 E 1-M 1000-1100 D LB4 IR LB8 OS B 1000-1100 OD5 C2 PS3 ISO 19818-1 OS E CE |
| Cover plate (Polycarbonate) | Safety plate | OS B CE |
What's Included
- Welding helmet
- Optrel IsoFit® headgear
- Storage Bag
- Micro USB Charging Cable
- Front Cover Lens
- Warranty Card
Warranty
- From the date of purchase: 2 years for manufacturing and material defects, 6 months for the battery
- 1 year warranty extension (except batteries) for online product registration within the first 6 months
