Straight Push To Connect Fitting 6 mm OD x 1/4" NPT Male
Pneumatic Push to Connect Fitting, Nickel Plated Brass Straight Male Connector. Designed for use with Polyurethane or Nylon tubing. Quick and Reliable connections and Reusable: Multiple connections/disconnections. Pre-coated threads are ready to use without additional sealing
Used to connect gas 6mm gas line hose to a standard Argon, Nitrogen regulator for the THEO hand held laser welding machine
- Model: BMTC 6-N02
- Tubing: 6 mm OD
- Thread: 1/4" NPT Male
- Body Material: Nickel Plated Brass
Specifications
- Fluid Type: Air
Operating Pressure: 0- 200 PSI
Working Temperature: 32°F to 140°F (0°C to 60°C)
Metallic Body: Nickel Plated Brass
O-Ring: NBR (Acrylonitrile butadiene rubber)
Packing: NBR (Acrylonitrile butadiene rubber)
Back Ring: POM (Polyoxymethylene plastic)
Lock Claws: Stainless Steel
Collar: Nickel Plated Brass
Sleeve: Nickel Plated Brass
This product is not D.O.T. (Department of Transportation) approved and should not be used for automotive applications.
