BuildPro Alpha 28 Welding Fixture Table, 1.2m x 1.2m

BuildPro Alpha 28 Welding Fixture Table

1.2m x 1.2m (Approx. 4' x 4') Nitrided - 28mm Bore Diameter Fixturing Holes

This product ships free of charge to USA (lower 48) and Canada. No import fees or duties are applied. Forklift or Loading Dock are required.

Each plate of the table is made from a low alloy tool steel that’s tough enough for use in the mold-making industry. After surface grinding and machining, each plate is further enhanced with a QPQ nitriding process that improves hardness, corrosion resistance, and resistance to weld spatter.

Plates on the table can be repositioned, or removed as applications dictate; a patented plate locating system means the spacing of the holes are always within tolerance without the need for special re-calibration.

Specifications

• Size: 1.2m x 1.2m

• Flatness: +/- .004 inches per foot

• Finish: Plasma Nitride

• Hole diameter: 28mm

• Hole spacing: 100mm

• Plate thickness: 1 inch +/- .002 (25mm)

• Weight (pounds): 1550

• Dimensions (LxWxH): 47.24 x 47.24 x 7.87 inches

BuildPro Alpha 28 Brochure | View All BuildPro Tables and Accessories

 Please allow a 5 business day processing time.  Orders are shipped direct from the manufacturer and do not incur import fees.
